The SwiftBox is a revolutionary Skybox otherwise known as a MISP (Modular Insulated Skylight Panel) designed and built to function as a skylight modular member for major commercial Insulated panels. With flexibility in thermal and lighting performance and an inbuilt anti-fall protection, the Swiftbox is a cost effective ‘plug and play’ skylight solution that achieves seamless underside finish and comparable span capability to its adjoining roof panel system.
SwiftBox
Skylight
Benefits
Factory assembled to direct fit to Insulated panel manufacturer profile achieving seamless underline finish and fast installation (noflashing required).
Comparable Span capability to PIR manufacturers multi-span performance in single spans eliminating costly structural steel and freight.
Inbuilt anti-fall protection as per AS4389 eliminating need for mesh for up to 6.5m span.
Optimal UV filtered light with acoustic and thermal insulation.
Australian assembled with complete Australian made aluminium and Class 4 screws for corrosion resistance.
Ability to facilitate concealed electrical cable pass through.
Maximum lengths up to 11.8m (subject to MOQ and availability).
Suitable for all commercial applications including aquatic & highly corrosive environments (when powder coated and installed as per instructions).
Cost
Effective
Simple and fast installation reduces labour cost and equipment hire.
Pre-assembled to need only fix-down screws and seal tape reducing material cost.
Seamless underside finish colour matched eliminates cost of flashing, fixing, sealing, and extended scissor lift hire.
Comparable spaning distance to adjoining insulated panel eliminating cost of additional steel structure.
